LUXLINE™ LED LIGHT STRIP - RGB
LUXLINE™ LED LIGHT STRIP - RGB
For applications requiring dazzling creativity and an electrifying burst of color, we offer our slim 6mm LUXLINE™ RGB LED Light Strip. Like all of our LUXLINE™ products, cut, flex, and curve this LED strip to fit your specific custom applications with brilliant, colorful illumination. This RGB strip works with multiple controls that can be used to control each strip individually for complex installations.
Safety Standard
- UL Listed E477011
- CUL Listed
- CE
- Limited Warranty 5 years
Parameters
- LED Type EPISTAR 2735 LED
- LED Count 24 LEDs/ft (84 LEDs/m)
- Dimensions 0.24″ (w) x 0.08″ (h) [6mm (w) x 2.1mm (h)]
- LED Pitch 0.47″ (11.9mm)
- LED Strip Width 0.24″ (6mm)
- LED Node Size 2735
- Roll Length 16 ft 3/8 in (5m)
Installation
- Field Cuttable 1.41″ (35.7mm), every 3 LEDs
- Mounting 3M™ Adhesive
- Heat Sink Not required
- Environment Indoor/dry location
- IP Rating¹ IP22
- Operating Temperature -40°F ~179°F (-40~82°C)
- Ambient Temperature -4°F ~140°F (-20~60°C)
¹Custom IP Ratings—including EXTERIOR applications (IP65, IP67, IP68)—available upon request.
Photometrics
- Wide Beam Angle 120°
- Lamp Life 50,000+ hours
- Standard Color Temperatures
- Red – 625nm
- Green – 525nm
- Blue – 465nm
Power Supply
- Input Voltage 12 VDC & 24VDC constant voltage
- Input Current 0.17 A/ft (0.56 A/m)
- Power Consumption 3.07 W/ft (10.08 W/m)
- Wire Size 20 AWG 4 Wire
- Please use only with Class 2 power supply
- Connector Type
- Molex®
- DC Barrel Jack
- Hardwire
Compatible Control
- DMX Control
- Wi-Fi Control for Smart Devices
- Radio Frequency (RF) Remote Control
- 0-10V
LUXLINE™ is LEDCONN’s LED light strip, made to illuminate any unique shape and is easy to use. This product will inspire designers to create stunning lighting applications with its vast capabilities and creative potential. This product is cuttable to provide a variety of lengths to best fit your application. The flexible design allows for applications of all shapes and sizes.
Featuring a slim width of only 6mm, simply cut, flex, and curve this LED strip and watch how snugly it fits highly customized and narrow applications with brilliant illumination. While LUXLINE™ RGB is great for a variety of standard retail, architectural, display, and signage applications that utilize LED light strips, this light strip series shines best utilized in stage and entertainment applications.
Product Features
Optimal Color Rendering
80% Energy Efficient
Outstanding Brightness
Custom Roll Lengths
Long LED Lifespan
Custom Colors
Flex & Curve
Constant Voltage – 12V/24V
Slim Width
Cuttable
Wide Beam Angle
Certifications
Applications:
- Stage & Entertainment Accent Lighting
- High-End Residences
- Nightclubs, Restaurants & Theaters
- Theme Park Rides & Attractions
- Indoor Accent Lighting
- Under Cabinet LED Lighting
- Showcase & Bookshelf Lighting
- Retail Merchandising Displays
- Illuminated POP Displays
- Path and Contour Marking
- Signage
…And Many More!
